Bricks are one of the oldest known building materials dating back to 7000BC where they were first found in southern Turkey and around Jericho. The first bricks were sun dried mud bricks. Fired bricks were found to be more resistant to harsher weather conditions, which made them a much more reliable brick for use in permanent buildings, where mud bricks would not have been sufficient. Fired brick were also useful for absorbing any heat generated throughout the day, then releasing it at night

The Ancient Egyptians also used sun dried mud bricks as building materials, evidence of which can still be seen today at ruins such as Harappa Buhen and Mohenjo-daro. Paintings on the tomb walls of Thebes portray slaves mixing, tempering and carrying clay for the sun dried bricks. These bricks also consisted of a 4:2:1 ratio which enabled them to be laid more easily.

The Romans further distinguished those which had been dried by the sun and air and those bricks which were burnt in a kiln. Preferring to make their bricks in the spring, the Romans held on to their bricks for 2 years before they were used or sold. They only used clay which was whitish or red for their bricks.

Using mobile kilns, the Romans were successful in introducing kiln fired bricks to the whole of the Roman Empire. The bricks were then stamped with the mark of the legion who supervised the brick production. These bricks differed from other ancient bricks in size and shape. Roman bricks were more commonly round, square, oblong, triangular or rectangular. The kiln fired bricks were generally 1 or 2 Roman foot by 1 Roman foot, but with some larger bricks at up to 3 Roman feet. The Romans preferred this type of brick making during the first century of their civilisation and used the bricks for public and private buildings all over the empire.

The Greeks also considered perpendicular brick walls more durable than stone walls and used them for public edifices. They also realised how the modern brick was less susceptible to erosion than the old marble walls.

During the 12th century bricks were reintroduced to northern Germany from northern Italy. This created the brick gothic period which was a reduced style of Gothic architecture previously very common in northern Europe. The buildings around this time were mainly built from fired red clay bricks. Brick Gothic style buildings can be found in the Baltic countries Sweden, Denmark, Poland, Germany, Finland, Lithuania, Latvia, Estonia, Belarus and Russia. The brick gothic period can be categorized by the lack of figural architectural sculptures which had previously been carved in stone. The Gothic figures were impossible to create out of bulky bricks at that time, but could be identified by the use of split courses of bricks in varying colours, red bricks, glazed bricks and white lime plaster. Eventually special shaped bricks were introduced which would imitate the architectural sculptures.

During the renaissance and Baroque periods, exposed brick walls became unpopular and brickwork was generally covered by plaster. Only during the mid 18th century did visible brick walls again regain some popularity.

Bricks now

Good quality bricks have a major advantage over stone as they are reliable, weather resistant and can tolerate acids, pollution and fire. Bricks can be made to any specification in colour, size and shape which makes bricks easier to build with than stone. Brickwork is also much cheaper than cut stone work. However there are some bricks which are more porous and therefore more susceptible to dampness when exposed to water. For best results in any construction work, the correct brick must be chosen in accordance with the job specifications.

Brick Composition

Manufacturing Processes

Handmade bricks used to be very commonly used throughout the UK. The process involves putting the clay, water and additives into a large pit where it is all mixed together by a tempering wheel generally still powered by horse power. Once the mixture is of the correct consistency, the clay is removed and pressed into moulds by hand. To prevent the brick from sticking to the mould, the brick is coated in either sand or water. Named ‘slop moulding’ when dipped in water and ‘sand struck’ when coated in sand. Coating the brick with sand however gives an overall better finish to the brick. Once shaped, the bricks are laid outside to dry by air and sun where they will be drying for three to four days.

After this process the bricks are then transferred to the kiln for burning. If green bricks are left outside for the drying process and are left out during a shower; the water leaves an indentation of the brick is considered very undesirable. However this does not affect the strength properties of the bricks. Bricks are now more generally made by large scale manufacturing processes using machinery. This is a large scale effort and produces bricks which have been burned in patent kilns. There are three different types of manufacturing process for machine made bricks - the soft mud process, the stiff mud process and the dry clay process for which machines are specifically designed.

The ‘Soft mud ‘process is similar to that of handmade bricks. In the Soft Mud process that clay contains too much water to be extruded as the clay is left to soak in water for 24 hours. For this process three pits are usually in operation at any one time to keep the production flowing. Occasionally the clay is worked in a pug mill before being thrown into the machine. Due to the 20% water content of the clay, wooden moulds are generally used and are lined with either oil or sand to stop the clay sticking. After being drawn from the machine the filled moulds are emptied by hand and the bricks taken to the dry shed. So the soft mud bricks can be dried properly, both handmade soft mud bricks and machine made (more mass produced) bricks will both be placed in a large dryer which is separate from the extrusion dryer.

The ‘Stiff mud’ process differs because only enough water to create plasticity is added to the clay, approximately 12% water. Clay is then extruded through a ‘die’ to produce a long stream of pressed clay which is then cut to size by the machine. The die sizes and cutter wire are calculated to compensate for the shrinkage of the brick during drying and firing. Attachments can also be added to the die which gives the brick its texture from brush, roll, and scratch to roughen. Green bricks are then dried out carefully to ensure a consistent colour and strength. Because Soft Mud bricks have been created under little or no pressure, their density is not as great as that of Stiff Mud bricks. It has been argued that when Soft Mud bricks have been made and burned properly they are possibly the most durable brick. However Stiff mud bricks can have defects or planes of separation which can affect the bricks durability. However as Stiff Mud bricks are becoming increasingly cheaper to produce these are becoming the more popular.

The ‘Repressing’ of a brick is to re-shape the brick or round of any corners dependent on specification. Both types of soft mud and stiff mud bricks can be repressed when they are only partially dried. This is done by placing the bricks in metal moulds and putting them under great pressure before burning. Pressed bricks however are machine moulded bricks where the clay being used is already nearly dry. This process can make a significant difference on the appearance of the bricks. Bricks made using this process generally are more difficult to compress. Dry pressed bricks however are now commonly used for face bricks. Pressed bricks generally mean dry pressed bricks, but many face bricks are made by repressing soft mud bricks.

‘Cement’ bricks made from Portland cement, these bricks are machine moulded into size and shape to match the size of clay bricks. These are extensively used in some regions.

‘Hollow, Terracotta or Tile’. This type of product can made into practically and size or shape for any kind of use. Blocks made of terra-cotta are light and durable. For use in partitions the terra-cotta is mixed with sawdust which burns off in the kiln, but creates a more porous brick. Terra-cotta can be glazed or unglazed.

Facing Bricks Types of:-

Arch and Clinker bricks This term is used for bricks which are burned immediately. They are over burnt and sometimes distorted in shape. Body, Cherry and/or hard bricks. These bricks are of a higher quality and are generally the bricks that were in the centre of the pile of bricks which have been burned. These bricks are top bricks as they have a higher overall quality and finish. Cherry is used as a term when the clay which has been used burns red.

Salmon, Pale or Soft bricks. These are the bricks which were nearer to the outside of the kiln during burning which means they are slightly under burnt. These bricks are generally softer than the bricks taken from the centre of the kiln are therefore are of a lesser quality, although this does not affect the overall shape of the brick. These bricks are generally used for the interior of walls.

Waterstruck Brick This type of brick is a soft mud moulded brick. It uses alluvial clay which deposited at the end of the last ice age. The clay is pressed into mould lined with silicate. When the bricks are removed from their mould, they are left with a textured effect which can only be achieved using this method. This type of brick looks old and handmade even when new.

Engineering Bricks Engineering bricks are called so due to their overall strength and water absorption. The Class A brick has strength of 125N/mm² and water absorption of less than 4.5%. Class B engineering bricks have a strength greater than 75N/mm² and water absorption of less than 7%. Traditionally used in civil engineering, these bricks are also useful for damp courses and structural design.

Bullnose Bricks These special bricks are used when round edges are needed, for gate recesses, quadrants or arches.

Different uses for bricks

Ordinary bricks or facebricks and have regular shape and colour used for the outside of building etc.

Bricks can be made to virtually any specification,Overall strength and water absorption of clay bricks Compressive strengths vary from 5 N/mm2 to 125N/mm2

Water absorption varies from 6-26% dependant on brick type

Up Draft Kiln. Used more frequently for handmade bricks and in small brick yards, this old fashioned kiln is only up to 15 feet high.

The colour of brick is influenced by the chemical and mineral content of the mixture but also how high the temperature was during burning. Bricks are generally red, but an increase in temperature can change them to dark red, purple, brown or grey. Bricks containing silicate depend on the colourant used. The colour and place of manufacture is reflected in the brick names.

Mortar is then graded between 1 and 5 depending on strength. 5 being the weakest.

Lime Mortar

White and Coloured Mortar

Cement Mortars

For example

The solutions change the produced colour of the brick, it is not a paint simply applied to the face of the brick, it will naturally whether just as the normal brick would, mature over the years. All work is fully guaranteed for the life of the brick.

Brickwork Bonds

This bond is the most commonly used today. Bricks used to make this bond are just half a

English Bond

Pointing

Different types of Pointing
